1" CPVC Socket Stub Out Elbow with Square Mounting Flange, 11" x 10"

SKU: S73006

Connects to CPVC tubing (Solvent Weld)
Closed end for pressure testing
Flange for nailing to a stud
cUPC approved for use in USA and Canada
Meets ASTM D2846, CSA B137.6
ASTM B88 type L copper tube
Complies with Section 1417(d) of the Safe Drinking Water Act, the lead content requirements of Section 116875 of the California Health & Safety Code, and NSF/ANSI 372-2016

This product must be purchased in increments of 1

Made to the highest quality standards, Jones Stephens' copper stub out elbows with open and closed ends for pressure testing are the professional, trusted choice for your installation. Install a stub out during the rough-in phase of your remodel or construction, and the exposed end will be ready for a connection to a fixture or device. These stub outs connect to CVPC tubing (solvent weld) and come complete with a flange for nailing to a stud. They are lead free and are tested and listed by IAPMO for approval for use in drinking water services in the USA and Canada.

Connects to CPVC tubing (Solvent Weld)
Closed end for pressure testing
Flange for nailing to a stud
cUPC approved for use in USA and Canada
Meets ASTM D2846, CSA B137.6
ASTM B88 type L copper tube
Complies with Section 1417(d) of the Safe Drinking Water Act, the lead content requirements of Section 116875 of the California Health & Safety Code, and NSF/ANSI 372-2016

AB100 Certified:N/A

CEC Listed:No

cUPC Listed:Yes

UPC Listed:Yes

End Connections:End Connections:Male CPVCCTS (Spun Closed For Testing)

ANSI Standard:ANSI Standard:ANSI 372-2016ANSI 61-2018

ASTM Standard:ASTM D2846-2019a

CEC Compliant:No

IAPMO Listed:Yes

Lead Law Compliant:Yes

MASS Approved:Yes

NSF Certified:No

NSF Standard:NSF Standard:NSF 372-2016NSF 61-2018

SDWA Compliant:Yes

HAZMAT:No

CAN Standard:CAN 61-2018

Products specifications

Product	Elbows
Style	with Mounting Flange
Type	CPVC Solvent Weld
Material	Copper
Size	1"
Length	11" x 10"
